Key Features

Excellent corrosion resistance in oxidizing and mildly reducing environments.
Outstanding ductility and formability for easy fabrication.
High impact toughness even at cryogenic temperatures.
Low density and high strength-to-weight ratio.
Excellent weldability and biocompatibility.
Non-magnetic and resistant to seawater corrosion.
Good resistance to erosion and cavitation damage.

Chemical Composition (% by weight)

Element	Content (%)
Titanium (Ti)	Balance
Iron (Fe)	≤ 0.20
Oxygen (O)	≤ 0.18
Carbon (C)	≤ 0.08
Nitrogen (N)	≤ 0.03
Hydrogen (H)	≤ 0.015

Mechanical Properties

Property	Metric	Imperial
Tensile Strength (min)	240 MPa	35 ksi
Yield Strength (0.2% offset)	170 MPa	25 ksi
Elongation	≥ 24%	≥ 24%
Hardness (Brinell)	Approx. 70 HB	Approx. 70 HB

Physical Properties

Property	Value
Density	4.51 g/cm³
Melting Point	1660°C
Thermal Conductivity	17 W/m·K
Electrical Resistivity	0.42 μΩ·m
Modulus of Elasticity	105 GPa

Standard Sizes

Product Form	Size Range	Finish Options
Rods / Bars	Diameter: 3 mm – 200 mm \| Length: Up to 6000 mm	Bright, Polished, Black, or Turned Finish
Sheets	Thickness: 0.5 mm – 10 mm \| Width: Up to 1500 mm \| Length: Up to 3000 mm	Cold Rolled, Hot Rolled, or Polished Finish
Plates	Thickness: 10 mm – 100 mm \| Width: Up to 2000 mm \| Length: Up to 6000 mm	Hot Rolled, Pickled, or Custom Finish

Applications

Chemical processing equipment and heat exchangers
Marine and seawater desalination systems
Aerospace and airframe components
Medical and pharmaceutical processing equipment
Pressure vessels and condenser tubing
Architecture and industrial piping systems
Heat recovery and pollution control systems

Key Features

Excellent corrosion resistance in oxidizing and mildly reducing environments.
High strength-to-weight ratio and good formability.
Excellent weldability and fabricability.
Outstanding resistance to seawater, brine, and chlorides.
Good ductility and toughness even at cryogenic temperatures.
Non-magnetic and biocompatible, suitable for medical use.
Performs well under high-temperature and high-pressure conditions.

Chemical Composition (% by weight)

Element	Content (%)
Titanium (Ti)	Balance
Iron (Fe)	≤ 0.30
Oxygen (O)	≤ 0.25
Carbon (C)	≤ 0.08
Nitrogen (N)	≤ 0.03
Hydrogen (H)	≤ 0.015

Mechanical Properties

Property	Metric	Imperial
Tensile Strength (min)	345 MPa	50 ksi
Yield Strength (0.2% offset)	275 MPa	40 ksi
Elongation	≥ 20%	≥ 20%
Hardness (Brinell)	Approx. 160 HB	Approx. 160 HB

Physical Properties

Property	Value
Density	4.51 g/cm³
Melting Point	1665°C
Thermal Conductivity	16.4 W/m·K
Electrical Resistivity	0.42 μΩ·m
Modulus of Elasticity	103 GPa

Standard Sizes

Product Form	Size Range	Finish Options
Rods / Bars	Diameter: 3 mm – 200 mm \| Length: Up to 6000 mm	Bright, Polished, Black, or Turned Finish
Sheets	Thickness: 0.5 mm – 10 mm \| Width: Up to 1500 mm \| Length: Up to 3000 mm	Cold Rolled, Hot Rolled, or Polished Finish
Plates	Thickness: 10 mm – 100 mm \| Width: Up to 2000 mm \| Length: Up to 6000 mm	Hot Rolled, Pickled, or Custom Finish

Applications

Heat exchangers, condensers, and pressure vessels
Marine and offshore equipment
Chemical processing and desalination systems
Aircraft hydraulic and fuel systems
Architectural and industrial structures
Medical devices and surgical instruments
Power generation and petrochemical industries

Key Features

Higher strength than Grade 1 and Grade 2 titanium.
Excellent corrosion resistance in oxidizing and mildly reducing environments.
Good weldability and fabricability.
High ductility and good formability.
Outstanding performance in marine and chemical process environments.
Non-magnetic and biocompatible material.
Resistant to erosion and cavitation in seawater applications.

Chemical Composition (% by weight)

Element	Content (%)
Titanium (Ti)	Balance
Iron (Fe)	≤ 0.30
Oxygen (O)	≤ 0.35
Carbon (C)	≤ 0.08
Nitrogen (N)	≤ 0.05
Hydrogen (H)	≤ 0.015

Mechanical Properties

Property	Metric	Imperial
Tensile Strength (min)	450 MPa	65 ksi
Yield Strength (0.2% offset)	380 MPa	55 ksi
Elongation	≥ 18%	≥ 18%
Hardness (Brinell)	Approx. 200 HB	Approx. 200 HB

Physical Properties

Property	Value
Density	4.51 g/cm³
Melting Point	1660°C
Thermal Conductivity	16.4 W/m·K
Electrical Resistivity	0.42 μΩ·m
Modulus of Elasticity	103 GPa

Standard Sizes

Product Form	Size Range	Finish Options
Rods / Bars	Diameter: 3 mm – 200 mm \| Length: Up to 6000 mm	Bright, Polished, Black, or Turned Finish
Sheets	Thickness: 0.5 mm – 10 mm \| Width: Up to 1500 mm \| Length: Up to 3000 mm	Cold Rolled, Hot Rolled, or Polished Finish
Plates	Thickness: 10 mm – 100 mm \| Width: Up to 2000 mm \| Length: Up to 6000 mm	Hot Rolled, Pickled, or Custom Finish

Applications

Chemical processing equipment
Heat exchangers and pressure vessels
Marine and offshore structures
Aircraft hydraulic and structural components
Desalination plants and condensers
Power generation and gas processing industries
Architectural and industrial assemblies requiring high corrosion resistance

Key Features

Highest strength among commercially pure titanium grades.
Excellent corrosion resistance in a wide range of environments.
Good weldability and formability for fabrication.
High resistance to oxidation and crevice corrosion.
Superior biocompatibility for medical applications.
Non-magnetic and lightweight metal.
Good performance in cryogenic and elevated temperature service.

Chemical Composition (% by weight)

Element	Content (%)
Titanium (Ti)	Balance
Iron (Fe)	≤ 0.50
Oxygen (O)	≤ 0.40
Carbon (C)	≤ 0.08
Nitrogen (N)	≤ 0.05
Hydrogen (H)	≤ 0.015

Mechanical Properties

Property	Metric	Imperial
Tensile Strength (min)	550 MPa	80 ksi
Yield Strength (0.2% offset)	480 MPa	70 ksi
Elongation	≥ 15%	≥ 15%
Hardness (Brinell)	Approx. 235 HB	Approx. 235 HB

Physical Properties

Property	Value
Density	4.51 g/cm³
Melting Point	1660°C
Thermal Conductivity	16.4 W/m·K
Electrical Resistivity	0.43 μΩ·m
Modulus of Elasticity	105 GPa

Standard Sizes

Product Form	Size Range	Finish Options
Rods / Bars	Diameter: 3 mm – 200 mm \| Length: Up to 6000 mm	Bright, Polished, Black, or Turned Finish
Sheets	Thickness: 0.5 mm – 10 mm \| Width: Up to 1500 mm \| Length: Up to 3000 mm	Cold Rolled, Hot Rolled, or Polished Finish
Plates	Thickness: 10 mm – 100 mm \| Width: Up to 2000 mm \| Length: Up to 6000 mm	Hot Rolled, Pickled, or Custom Finish

Applications

Aerospace structural components and engine parts
Marine and offshore hardware
Chemical processing equipment and reactors
Heat exchangers, condensers, and pressure vessels
Medical implants, surgical devices, and dental instruments
Power generation and desalination plants
Industrial equipment requiring strength and corrosion resistance

Key Features

High strength-to-weight ratio with excellent corrosion resistance.
Superior resistance to fatigue and stress corrosion cracking.
Excellent mechanical properties up to 400°C (752°F).
Good weldability and machinability with proper techniques.
Excellent biocompatibility — suitable for medical and dental use.
Superior performance in seawater and oxidizing environments.
Ideal for high-performance aerospace and marine structures.

Chemical Composition (% by weight)

Element	Content (%)
Titanium (Ti)	Balance
Aluminium (Al)	5.5 – 6.75
Vanadium (V)	3.5 – 4.5
Iron (Fe)	≤ 0.40
Oxygen (O)	≤ 0.20
Carbon (C)	≤ 0.08
Nitrogen (N)	≤ 0.05
Hydrogen (H)	≤ 0.015

Mechanical Properties

<

Property	Metric	Imperial
Tensile Strength (min)	895 MPa	130 ksi
Yield Strength (0.2% offset)	828 MPa	120 ksi
Elongation	≥ 10%	≥ 10%
Reduction of Area	≥ 25%	≥ 25%
Hardness (Rockwell C)	36 HRC	36 HRC

Physical Properties

Property	Value
Density	4.43 g/cm³
Melting Point	1660°C
Thermal Conductivity	6.7 W/m·K
Electrical Resistivity	1.71 μΩ·m
Modulus of Elasticity	113.8 GPa

Standard Sizes

Product Form	Size Range	Finish Options
Rods / Bars	Diameter: 6 mm – 250 mm \| Length: Up to 6000 mm	Bright, Polished, Turned, or Ground Finish
Sheets	Thickness: 0.5 mm – 10 mm \| Width: Up to 1500 mm \| Length: Up to 3000 mm	Cold Rolled, Hot Rolled, or Polished Finish
Plates	Thickness: 10 mm – 100 mm \| Width: Up to 2000 mm \| Length: Up to 6000 mm	Hot Rolled, Pickled, or Custom Finish

Applications

Aerospace structures and jet engine components
Marine and offshore equipment
Chemical processing and desalination systems
Medical implants and surgical instruments
High-performance automotive components
Sports equipment and high-stress industrial parts
Heat exchangers and power generation systems

Key Features

Excellent corrosion resistance, especially in oxidizing and reducing acid environments.
Enhanced resistance to crevice and pitting corrosion due to palladium addition.
High strength-to-weight ratio and low density.
Good weldability and formability comparable to Grade 2 titanium.
Excellent resistance to seawater and chloride media.
Outstanding performance in both oxidizing and mildly reducing conditions.
Long service life in chemical and marine environments.

Chemical Composition (% by weight)

Element	Content (%)
Titanium (Ti)	Balance
Palladium (Pd)	0.12 – 0.25
Iron (Fe)	≤ 0.30
Oxygen (O)	≤ 0.25
Carbon (C)	≤ 0.08
Nitrogen (N)	≤ 0.03
Hydrogen (H)	≤ 0.015

Mechanical Properties

Property	Metric	Imperial
Tensile Strength (min)	345 MPa	50 ksi
Yield Strength (0.2% offset)	275 MPa	40 ksi
Elongation	≥ 20%	≥ 20%
Reduction of Area	≥ 30%	≥ 30%
Hardness (Rockwell B)	80 HRB	80 HRB

Physical Properties

Property	Value
Density	4.51 g/cm³
Melting Point	1660°C
Thermal Conductivity	17 W/m·K
Electrical Resistivity	0.55 μΩ·m
Modulus of Elasticity	105 GPa

Standard Sizes

Product Form	Size Range	Finish Options
Rods / Bars	Diameter: 6 mm – 200 mm \| Length: Up to 6000 mm	Bright, Polished, Turned, or Ground Finish
Sheets	Thickness: 0.5 mm – 10 mm \| Width: Up to 1500 mm \| Length: Up to 3000 mm	Cold Rolled, Hot Rolled, or Polished Finish
Plates	Thickness: 10 mm – 100 mm \| Width: Up to 2000 mm \| Length: Up to 6000 mm	Hot Rolled, Pickled, or Custom Finish

Applications

Chemical processing and heat exchanger tubing
Desalination and marine equipment
Pulp and paper industry processing equipment
Power generation and condenser systems
Chlorate manufacturing and industrial scrubbers
Oil & gas and offshore environments
High-performance aerospace and marine components

Key Features

Outstanding corrosion resistance in oxidizing and reducing acid environments.
Improved mechanical strength compared to commercially pure grades.
Excellent resistance to pitting and crevice corrosion.
Good weldability and cold formability.
High strength-to-weight ratio and low density.
Enhanced durability in chloride-containing environments.
Excellent thermal and mechanical stability.

Chemical Composition (% by weight)

Element	Content (%)
Titanium (Ti)	Balance
Molybdenum (Mo)	0.2 – 0.4
Nickel (Ni)	0.6 – 0.9
Iron (Fe)	≤ 0.30
Oxygen (O)	≤ 0.25
Carbon (C)	≤ 0.08
Nitrogen (N)	≤ 0.03
Hydrogen (H)	≤ 0.015

Mechanical Properties

Property	Metric	Imperial
Tensile Strength (min)	415 MPa	60 ksi
Yield Strength (0.2% offset)	345 MPa	50 ksi
Elongation	≥ 18%	≥ 18%
Reduction of Area	≥ 30%	≥ 30%
Hardness (Rockwell B)	85 HRB	85 HRB

Physical Properties

Property	Value
Density	4.51 g/cm³
Melting Point	1660°C
Thermal Conductivity	16.4 W/m·K
Electrical Resistivity	0.56 μΩ·m
Modulus of Elasticity	105 GPa

Standard Sizes

Product Form	Size Range	Finish Options
Rods / Bars	Diameter: 6 mm – 200 mm \| Length: Up to 6000 mm	Bright, Polished, Turned, or Ground Finish
Sheets	Thickness: 0.5 mm – 10 mm \| Width: Up to 1500 mm \| Length: Up to 3000 mm	Cold Rolled, Hot Rolled, or Polished Finish
Plates	Thickness: 10 mm – 100 mm \| Width: Up to 2000 mm \| Length: Up to 6000 mm	Hot Rolled, Pickled, or Custom Finish

Applications

Chemical process equipment and heat exchangers
Desalination and marine systems
Pulp and paper bleaching plants
Oil & gas and offshore equipment
Aerospace and defense components
Power generation condensers and piping
Industrial reactors and storage vessels

Key Features

Excellent balance between strength, formability, and corrosion resistance.
Higher strength than Grades 1–4 while retaining good ductility.
Exceptional resistance to oxidation and corrosion in marine and chemical environments.
High strength-to-weight ratio for aerospace and high-performance engineering applications.
Good cold formability and weldability.
Stable performance at moderately elevated temperatures.
Biocompatible – suitable for medical and surgical instruments.

Chemical Composition (% by weight)

Element	Content (%)
Titanium (Ti)	Balance
Aluminum (Al)	2.5 – 3.5
Vanadium (V)	2.0 – 3.0
Iron (Fe)	≤ 0.25
Oxygen (O)	≤ 0.20
Carbon (C)	≤ 0.08
Nitrogen (N)	≤ 0.05
Hydrogen (H)	≤ 0.015

Mechanical Properties (Typical Values)

Property	Metric	Imperial
Tensile Strength (min)	620 MPa	90 ksi
Yield Strength (0.2% offset)	483 MPa	70 ksi
Elongation	≥ 15%	≥ 15%
Reduction of Area	≥ 25%	≥ 25%
Hardness (Rockwell B)	90 HRB	90 HRB

Physical Properties

Property	Value
Density	4.48 g/cm³
Melting Point	1649°C
Thermal Conductivity	6.7 W/m·K
Electrical Resistivity	1.8 μΩ·m
Modulus of Elasticity	105 GPa

Standard Sizes

Product Form	Size Range	Finish Options
Rods / Bars	Diameter: 6 mm – 200 mm \| Length: Up to 6000 mm	Bright, Polished, Turned, or Ground Finish
Sheets	Thickness: 0.5 mm – 10 mm \| Width: Up to 1500 mm \| Length: Up to 3000 mm	Cold Rolled, Hot Rolled, or Polished Finish
Plates	Thickness: 10 mm – 100 mm \| Width: Up to 2000 mm \| Length: Up to 6000 mm	Hot Rolled, Pickled, or Custom Finish

Applications

Aerospace tubing and structural components
Marine hardware and offshore equipment
Chemical process and desalination plants
Automotive exhaust and performance parts
Medical and surgical instruments
Heat exchangers and condenser tubing
Sports equipment and lightweight frameworks

Key Features

High tensile and yield strength compared to many standard titanium alloys.
Good strength-to-weight ratio and excellent fatigue resistance.
Better formability and weldability than many high-strength titanium alloys.
Reasonable corrosion resistance in many marine and industrial atmospheres.
Suitable for rods, sheets & plates in structural, aerospace or high-performance uses.

Chemical Composition (% by weight)

Element	Content (%)
Titanium (Ti)	Balance
Molybdenum (Mo)	≈ 11.0 – 12.0
Zirconium (Zr)	≈ 5.5 – 6.5
Tin (Sn)	≈ 4.0 – 5.0
Iron (Fe)	≤ 0.25
Oxygen (O)	≤ 0.20
Carbon (C)	≤ 0.08
Nitrogen (N)	≤ 0.05
Hydrogen (H)	≤ 0.015

Mechanical Properties

Property	Typical Value	Condition
Tensile Strength (min)	900 MPa (≈ 130 ksi)	Solution treated & aged
Yield Strength (0.2% offset)	830 MPa (≈ 120 ksi)	Solution treated & aged
Elongation	≥ 10 %	Solution treated & aged
Hardness (Rockwell C)	≈ 37 HRC	Solution treated & aged

Physical Properties

Property	Value
Density	≈ 5.06 g/cm³
Melting Point	≈ 1650-1700 °C
Thermal Conductivity	≈ 6.5 W/m·K
Electrical Resistivity	≈ 1.7 µΩ·m
Modulus of Elasticity	≈ 110 GPa

Standard Sizes

Product Form	Size Range	Finish Options
Rods / Bars	Diameter: 6 mm – 200 mm \| Length up to 6000 mm	Bright, Turned, Ground
Sheets	Thickness: 0.5 mm – 10 mm \| Width up to 1500 mm \| Length up to 3000 mm	Cold Rolled, Hot Rolled, Polished
Plates	Thickness: 10 mm – 100 mm \| Width up to 2000 mm \| Length up to 6000 mm	Hot Rolled, Pickled, Custom Finish

Applications

Aerospace structural components and fastening systems
High-performance marine hardware and subsea equipment
High-cycle fatigue structural frames and lightweight assemblies
Pressure vessels and piping systems in aggressive or high-stress environments
Sports and performance engineering components requiring high strength and lightweight

Key Features

Enhanced corrosion resistance in reducing and oxidizing environments.
Superior weldability and formability.
High strength compared to commercially pure titanium grades.
Excellent resistance to crevice and pitting corrosion in chloride environments.
Suitable for both elevated temperature and marine service applications.

Chemical Composition (% by weight)

Element	Content (%)
Titanium (Ti)	Balance
Molybdenum (Mo)	0.2 – 0.4
Nickel (Ni)	0.6 – 0.9
Iron (Fe)	≤ 0.30
Oxygen (O)	≤ 0.25
Carbon (C)	≤ 0.08
Nitrogen (N)	≤ 0.03
Hydrogen (H)	≤ 0.015

Mechanical Properties

Property	Typical Value	Condition
Tensile Strength (min)	550 MPa (≈ 80 ksi)	Annealed
Yield Strength (0.2% offset)	480 MPa (≈ 70 ksi)	Annealed
Elongation	≥ 18 %	Annealed
Hardness (Rockwell B)	≈ 80 HRB	Annealed

Physical Properties

Property	Value
Density	4.51 g/cm³
Melting Point	1665 °C
Modulus of Elasticity	105 GPa
Thermal Conductivity	16.0 W/m·K
Electrical Resistivity	1.7 µΩ·m

Standard Sizes

Product Form	Size Range	Finish Options
Rods / Bars	Diameter: 6 mm – 200 mm \| Length up to 6000 mm	Bright, Turned, Ground
Sheets	Thickness: 0.5 mm – 10 mm \| Width up to 1500 mm \| Length up to 3000 mm	Cold Rolled, Hot Rolled, Polished
Plates	Thickness: 10 mm – 100 mm \| Width up to 2000 mm \| Length up to 6000 mm	Hot Rolled, Pickled, Custom Finish

Applications

Chemical processing equipment and heat exchangers
Marine and seawater handling systems
Power generation condensers and piping
Hydrometallurgical systems and desalinization plants
Industrial scrubbers, pumps, and pressure vessels

Key Features

Exceptional strength-to-weight ratio and excellent corrosion resistance.
Enhanced fracture toughness and fatigue resistance.
Superior biocompatibility for medical and surgical applications.
Improved weldability and formability over standard Grade 5 titanium.
Performs reliably in cryogenic and elevated temperature environments.

Chemical Composition (% by weight)

Element	Content (%)
Titanium (Ti)	Balance
Aluminum (Al)	5.5 – 6.75
Vanadium (V)	3.5 – 4.5
Iron (Fe)	≤ 0.25
Oxygen (O)	≤ 0.13
Carbon (C)	≤ 0.08
Nitrogen (N)	≤ 0.05
Hydrogen (H)	≤ 0.0125

Mechanical Properties

Property	Value	Condition
Tensile Strength (min)	860 MPa (≈ 125 ksi)	Annealed
Yield Strength (0.2% offset)	795 MPa (≈ 115 ksi)	Annealed
Elongation	≥ 14 %	Annealed
Reduction of Area	≥ 30 %	Annealed
Hardness (Rockwell C)	33 HRC (max)	Annealed

Physical Properties

Property	Value
Tensile Strength (min)	860 MPa (≈ 125 ksi)	Annealed
Yield Strength (0.2% offset)	795 MPa (≈ 115 ksi)	Annealed
Elongation	≥ 14 %	Annealed
Reduction of Area	≥ 30 %	Annealed
Hardness (Rockwell C)	33 HRC (max)	Annealed

Standard Sizes

Product Form	Size Range	Finish Options
Rods / Bars	Diameter: 6 mm – 200 mm \| Length up to 6000 mm	Bright, Turned, Ground
Sheets	Thickness: 0.5 mm – 10 mm \| Width up to 1500 mm \| Length up to 3000 mm	Cold Rolled, Hot Rolled, Polished
Plates	Thickness: 10 mm – 100 mm \| Width up to 2000 mm \| Length up to 6000 mm	Hot Rolled, Pickled, Custom Finish

Applications

Medical implants, orthopedic devices, and surgical instruments
Aerospace components and jet engine parts
High-performance automotive and motorsport components
Marine and offshore engineering equipment
Cryogenic and vacuum system components

Titanium Alloys Rods, Sheets & Plates

Our Products

Titanium Alloys Rods • Sheets • Plates

Overview

Key Features

Applications

Titanium Grades

Need Assistance?

Contact our team for more information @ +91-88808 08883 / +91-99017 48615
