Austenitic Stainless Steel

Austenitic Stainless Steel
Sheets • Coils • Plates • Pipes • Rods

Austenitic stainless steels are the most widely used stainless steel family, known for their excellent corrosion resistance, high ductility, good weldability, and superior formability. They contain high levels of chromium and nickel, with low carbon content, and are non-magnetic in the annealed condition.

Key Features

Excellent corrosion and oxidation resistance
High ductility and formability suitable for deep drawing
Non-magnetic in annealed condition
Good weldability without post-weld heat treatment
High toughness even at cryogenic temperatures
Resistant to acids, alkalis, and chloride environments (grade dependent)

Available Product Forms

Sheets
Coils
Plates
Pipes (Welded & Seamless)
Rods / Bars

Applications

Chemical processing equipment
Food and beverage processing
Pharmaceutical equipment
Oil & gas industry components
Heat exchangers and boilers
Architectural structures and cladding
Automotive and aerospace components
Kitchenware, utensils, appliances
Cryogenic equipment

Need Assistance?

Contact our team for more information @ +91-88808 08883 / +91-99017 48615

Request a Quote

Key Features

High strength with good ductility
Better toughness at low temperatures
Cost-effective alternative to Stainless Steel 304
Good corrosion and oxidation resistance
Excellent weldability and formability
Non-magnetic in annealed condition (may become slightly magnetic after cold work)

Chemical Composition (% by weight)

Element	Composition (%)
Carbon (C)	0.15 max
Manganese (Mn)	7.5 – 10.0
Chromium (Cr)	17.0 – 19.0
Nickel (Ni)	4.0 – 6.0
Silicon (Si)	1.0 max
Nitrogen (N)	0.25 max
Phosphorus (P)	0.060 max
Sulfur (S)	0.030 max

Mechanical Properties

Property	Value
Tensile Strength	515 MPa (min)
Yield Strength (0.2% Proof)	275 MPa (min)
Elongation	40% (min)
Hardness	95 HRB (max)

Physical Properties

Property	Value
Density	7.75 g/cm³
Melting Range	1400 – 1450°C
Thermal Conductivity	15 W/m·K at 100°C
Electrical Resistivity	0.78 µΩ·m
Modulus of Elasticity	200 GPa

Standard Sizes

Sheets & Plates

Thickness	Width	Length
0.5 mm – 50 mm	1000 / 1250 / 1500 mm	2000 – 6000 mm

Coils

Thickness	Width
0.5 mm – 6 mm	1000 / 1250 / 1500 mm

Pipes

Type	Size Range
Seamless / Welded	½" – 12"

Rods

Diameter Range
6 mm – 200 mm

Applications

Automotive trim and structural components
Utensils, kitchen equipment, cookware
Architectural panels, cladding, railings
Food processing equipment
Pressure vessels and storage tanks
Industrial fabrication and welded structures
Refrigeration and household appliances

Key Features

Excellent corrosion resistance in a wide range of environments
Good strength-to-weight ratio
High ductility and formability
Excellent weldability with or without filler metals
Non-magnetic in annealed condition
Resistant to food, chemical, and atmospheric corrosion

Chemical Composition (% by weight)

Element	Percentage (%)
Chromium (Cr)	18.0 – 20.0
Nickel (Ni)	8.0 – 11.0
Carbon (C)	≤ 0.08
Manganese (Mn)	≤ 2.0
Silicon (Si)	≤ 1.0
Sulfur (S)	≤ 0.030
Phosphorus (P)	≤ 0.045
Iron (Fe)	Balance

Mechanical Properties

Property	Value
Tensile Strength	515 – 750 MPa
Yield Strength (0.2% Proof)	205 MPa (min)
Elongation	40% (min)
Hardness (Brinell)	≤ 201 HB

Physical Properties

Property	Value
Density	8.0 g/cm³
Melting Range	1400 – 1450°C
Thermal Conductivity	16.3 W/m·K
Electrical Resistivity	0.72 μΩ·m
Modulus of Elasticity	193 GPa

Standard Sizes

Sheets & Plates

Thickness	Width	Length
0.5 mm – 50 mm	1000 / 1250 / 1500 mm	2000 / 2500 / 3000 mm

Coils

Thickness	Width
0.3 mm – 8 mm	600 – 1500 mm

Pipes

Type	Size Range
Seamless	½" – 8" NB
Welded	½" – 24" NB

Rods / Bars

Diameter
3 mm – 300 mm

Applications

Food processing equipment
Kitchenware and appliances
Chemical containers and tankers
Architectural and structural applications
Automotive trim and exhaust systems
Pharmaceutical equipment
Pressure vessels and heat exchangers
Piping systems for water and sanitation

Key Features

Low Carbon version of 304 – excellent weldability.
Superior corrosion resistance in mild environments.
Good formability and fabricability.
Non-magnetic in annealed condition.
Resistant to intergranular corrosion after welding.

Chemical Composition (% by weight)

Element	Percentage (%)
Carbon (C)	≤ 0.03
Chromium (Cr)	18.0 – 20.0
Nickel (Ni)	8.0 – 12.0
Manganese (Mn)	≤ 2.0
Silicon (Si)	≤ 1.0
Phosphorus (P)	≤ 0.045
Sulfur (S)	≤ 0.03
Nitrogen (N)	≤ 0.10

Mechanical Properties

Property	Value
Ultimate Tensile Strength	485 MPa (min)
Yield Strength (0.2% Offset)	170 MPa (min)
Elongation	40% (min)
Hardness	≤ 92 HRB

Physical Properties

Property	Value
Density	8.0 g/cm³
Melting Range	1400 – 1450°C
Thermal Conductivity	16.2 W/m·K (at 100°C)
Electrical Resistivity	0.72 µΩ·m
Modulus of Elasticity	193 GPa

Standard Sizes

Sheets & Plates

Thickness	Width	Length
0.5 mm – 50 mm	1000 / 1250 / 1500 mm	2000 – 6000 mm

Coils

Thickness	Width
0.3 mm – 8 mm	Up to 1500 mm

Pipes

Type	Size Range
Seamless	1/8" to 12" NB
Welded	1/2" to 36" NB

Rods / Bars

Form	Diameter
Round / Square / Hex	5 mm – 200 mm

Applications

Chemical processing equipment
Food & beverage industry components
Kitchen equipment & utensils
Architectural and structural applications
Pharmaceutical process vessels
Automotive trim & fittings
Piping systems and heat exchangers

Key Features

Excellent corrosion resistance, especially against chlorides and marine environments
Superior resistance to pitting and crevice corrosion
High tensile and creep strength at elevated temperatures
Good formability and weldability
Non-magnetic in annealed condition
Improved mechanical properties compared to 304

Chemical Composition (% by weight)

Element	Percentage (%)
Carbon (C)	0.08 max
Manganese (Mn)	2.00 max
Silicon (Si)	1.00 max
Phosphorus (P)	0.045 max
Sulfur (S)	0.030 max
Chromium (Cr)	16.0 – 18.0
Nickel (Ni)	10.0 – 14.0
Molybdenum (Mo)	2.00 – 3.00
Nitrogen (N)	0.10 max

Mechanical Properties

Property	Value
Tensile Strength	515 MPa (min)
Yield Strength (0.2% Proof)	205 MPa (min)
Elongation	40% (min)
Hardness (Brinell)	217 HB (max)

Physical Properties

Property	Value
Density	8.0 g/cm³
Melting Range	1375 – 1400°C
Thermal Conductivity	16.2 W/m·K
Electrical Resistivity	74 μΩ·cm
Modulus of Elasticity	193 GPa

Standard Sizes

Sheets & Plates

Thickness	Width	Length
0.5 mm – 50 mm	1000 / 1250 / 1500 / 2000 mm	As required / Standard: 2000–6000 mm

Coils

Thickness	Width
0.3 mm – 12 mm	1000–1500 mm

Pipes

Type	Size Range
Seamless	6 mm – 610 mm OD
Welded	12 mm – 2500 mm OD

Rods / Bars

Diameter Range
5 mm – 500 mm

Applications

Chemical processing equipment & pressure vessels
Marine components & seawater systems
Food processing & dairy equipment
Oil & gas refineries
Pharmaceutical machinery & reactors
Heat exchangers, boilers & condensers
Architectural and structural components
Pumps, valves, and fasteners

Key Features

Excellent corrosion resistance in harsh chemical and marine environments
Low carbon content prevents carbide precipitation during welding
Good mechanical strength and toughness at high and low temperatures
Non-magnetic in annealed condition
Superior formability and weldability
Widely used in pharmaceutical, food processing, and marine applications

Chemical Composition (% by weight)

Element	Percentage (%)
Carbon (C)	≤ 0.03
Chromium (Cr)	16 – 18
Nickel (Ni)	10 – 14
Molybdenum (Mo)	2 – 3
Manganese (Mn)	≤ 2
Silicon (Si)	≤ 1
Phosphorus (P)	≤ 0.045
Sulfur (S)	≤ 0.03
Iron (Fe)	Balance

Mechanical Properties

Property	Value
Tensile Strength	485 – 620	MPa
Yield Strength	170 – 275	MPa
Elongation	40 – 50	%
Hardness (Brinell)	170 – 217	HB
Modulus of Elasticity	193	GPa

Physical Properties

Property	Value
Density	8.0	g/cm³
Melting Point	1370 – 1400	°C
Thermal Conductivity	16	W/m·K
Electrical Resistivity	0.75	µΩ·m
Coefficient of Thermal Expansion	16	×10⁻⁶ /°C

Standard Sizes

Sheets

Thickness	Width
0.5 – 6 mm	1000 – 2000 mm

Plates

Thickness	Width	Length
6 – 150 mm	Custom Width	Custom Length

Pipes/ Tubes
Seamless & Welded

Outer Diameter	Wall Thickness
10 – 500 mm	1 – 50 mm

Rods/ Bars

Diameter Range	Forms
6 – 200 mm	Round, Square, Hexagonal

Applications

Food processing and pharmaceutical equipment
Chemical processing tanks and pipelines
Marine and salt-water applications
Heat exchangers and condenser tubes
Architectural and decorative applications
Medical and surgical instruments
